SPECIFICATIONS

Fingerprint reader: 96*96 sensor

Waterproof level: IP67

FRR: <1%

FAR: <0.002%

Material: Zinc alloy

Working voltage: 3.0-4.2V

Lock weight and Size: 90g

Lock size: 7.6*4.6*1.3 (CM)

Fingerprint sensor coverage: 72*64MM

Unlock speed: within 0.2 second

Working period: a year per power Charge

Led Light: three color light: red / blue /green

Battery: 3.7V lithium build in battery

Working temperature: -10~+40 degrees Celsius

Fingerprint capacity: record 10 times and save 10 groups

Reason to buy:

[High-tech Chips]:Using high-tech chips, fingerprint processing is faster, unlocking is more convenient, and your home is safer.

[10 Groups Fingerprint]: Up to 10 Groups Fingerprint Can be Stored to Unlock.Record 10 times and can save up to 10 groups fingerprints total, can be used by the whole family.

[0.2 Seconds Fast Unlock] : Up to 0.2 Seconds to fast unlock

[USB Charging/3.7V Lithium Battery]:Built-in 3.7V Lithium Battery, Electronic smart fingerprint padlock will max last half a year after fulling charge.

[Low Voltage Reminder]: When the voltage is low, the padlock will reminder you to charge.

[Security Lock for Locker]:Fingerprint padlock are made of aluminum alloy metal body and stainless steel shackle for superior cut resistance. High toughness steel wire, seamless joint is great for anti-thief, anti-dust and anti-erosion.

[Wide Application & Easy to Carry]:Lock can use it at home, outdoor, in office. Suitable for suitcases, golf bags, handbags, school lockers, furniture,
wardrobes, bicycle and other goods that you want to protect.

Note：

1.Please charge the fingerprint padlock more than 12 hours before the first time use.

2.Try to touch the sensor by different angle when lock records your fingerprint to ensure that it can recognize well during working.

3.Follow the steps strictly to record your fingerprint to make sure the process can be done easily.

Package list:

1* Fingerprint Padlock

1* USB Charging Cable

1* Manual

1* Color Box

Q & A:

Q1: Why any fingerprint can be unlocked ?

A1: Before entering the fingerprint, any fingerprint can be unlocked. If fingerprints are recorded, only the recorded fingerprints can be used to unlock the lock. Therefore, under normal circumstances, you must record more than two fingerprints to prevent the embarrassing situation of the fingers being scratched and unable to unlock.

Q2: How to do if the fingerprint can't be identified ?

A2: Usually due to fingerprint wear,peeling, scratches, dirty, wet fingers, or fingerprint collection window with smudge and water droplets, fingerprint identification is not successful. It is necessary to ensure that the fingers and fingerprint window are clean and dry .In case of finger scratches, it is recommended to enter at least 3 fingerprints registration after purchase.

Q3: How many fingerprints can be registered?

A3: Up to 10 groups of fingerprints can be registered .

Q4: How to do if the battery is dead ?

A4: Connect the charging port with Micro USB, the red light is on, indicating that it is charging, and it can be unlocked normally during charging. The light is off, indicating that it is fully charged.

Q5: How long does it continue after being fully charged ?

A5: After being fully charged, it can stand by for 12 months, and when the power is low, the red light flashes after unlocking.
